Rated lifting force：147kN Rated hook-hoisting force：78kN Lifting range：2270mm Lifting efficiency：127mm/once Initial height：50mm
It's suitable for hoisting track panef, bridge or other heavy artidle in railway construction. And it's also employed as a tool to hoist and transport various heavy articles in factory, mine, port, wharf daily operation. It possesses features of simple structure, reliability, easy manipulation, convenient maintenance, long lifting range, high hoisting speed and high rail lifting efficiency.
| Rated on the force | 147kN |
| Rated hook-hoisting force | 78kN |
| Lifting range | ≥2270mm |
| Lifting efficiency | 127mm/once |
| Initial height | 50mm |
| crow bar length (User provide for oneself) | 1.5m |
| Full-loaded max. operating force | 1920N |
| Overall size (Length x width x height) | 420×165×522mm |
| Weight | ≦25kg |
