TT Type Internal combustion tamping pick

Displacement:90cc
Power:1.8/5800KW/RP
idle speed:2300 ± 230RPM
working spped:5800 ± 200rpm
Vibration frequency:48HZ

Product Description:

Applying Scope

The TT type impact tamper is a portable intemal combustion vibratory tamper driven by a two-stroke engine that allows the engine to idle without triggering the impact mechanism, applicable to the replacement of sleeper work in the plate bed crushing work can also be used for railway lines, tumout tamping operations.Compared with the same kind of products, the replacement of the pickaxe-drill has the characteristics of simple operation, convenient maintenance, high impact, high efficiency and good shock absorption.

Technical Parameter

Displacement90cc
Power

1.8/5800KW/RP

idle speed2300 ± 230RPM
working speed

5800 ± 200rpm

Vibration frequency48HZ
Maximum no-load speed27500RPM
carburetordiaphragm
spark plugL6RTC
Spark Plug Gap0.8-0.9 MM
fuel gradeFC class two-stroke oil
oil93
gasoline volume mixture(25-30): 1
fuel consumption1.3 L/H
fuel tank volume1L
net weight (without fuel,pickaxe)

27.5 K

frequency

24H

Maximum Impact Energ

40J
Gear Box Lubrication100G 3 # extreme pressure composite lithium base lubricant
impact system grease100G 3 # extreme pressure composite lithium base lubricant
impact system oilDiesel Oil 15W/40 API: CD
impact system fuel consumption100ML
impact system fuel consumption0.015 L/h
