Engine size (length x width x height)：450×340×790mm Engine type：two-stroke gasoline engine Displacement：80M1 No-tool mass：23kg Impact Frequency：300MIN
· Breaking and dismantling in highway construction and civil engineering:
· Vibrating the crushed stones under the rails in railway construction;
· Replacing different maoinery, the machine can be broken, chipping, digging, tamping and other work;
· The machine is powered by two-stroke gasoline engine, with strong power and high working efficiency.
· The machine is compact and reasonable in structure, beautiful in appearance, convenient in carrying and operation.
· It is safe in use and convenient in maintenance.
Engine size (length x width x height) | 450×340×790mm |
| Engine type | two-stroke gasoline engine |
| Displacement | 80M1 |
| No-tool mass | 23kg |
| Impact Frequency | 300MIN |
Impact Energy | 40J |
Clutch Spee | 2500 + 250r/Mi |
idle spee | 1800 ± 180r/Mi |
| operating speed | 4250R/Min |
| fuel | gasoline and oil volume ratio (25-30): 1 |
| Fuel Tank Volume | 2.4L |
| impact system grease | lithium-base grease |
