Petrol engine power：≥1.42KW Petrol engine rpm：28500r/min Max. drilling diameter：45mm Max. stroke：200mm Drilling hole time：≤50s
NLQ-45 Type intermal combustion concrete drilling machine it's suitable for drilling various concrete sleeper bolt in the occupied track condition. Through the trepanning principle, drilling operation can be done at any spot of the concrete sleeper. And after the bolt is fetched, the sleeper bolt can be re-anchored in the drilled hole.
It adopts a split structure with the main frame being separated from the fixed seat. The drilling operation can be done through using the main frame with the fixed seat or using the main frame without the fixed seat. It features high working efficiency, wide scope of application, off-track in fast speed, high safety performance, alleviating workers' labor intensity. It's an indispensable tool to beemployed in track laying and maintenance operation.
| Petrol engine power | ≥1.42KW |
| Petrol engine rpm | 28500r/min |
| Max. drilling diameter | 45mm |
| Drill bit model | Diamond thin wall dril bit φ40mm×260mm |
| Max. stroke | 200mm |
| Drilling hole time | ≤50s |
| Machine weight | 23kg |
